Support Customized Services SU Series Single Acting Air Pneumatic Cylinder With Accessories

Buy Now

Specifications

Other attributes
Condition	New
Place of Origin	ZHE
Weight (KG)	1
warranty:	1 Year
Showroom Location	None
Applicable Industries:	Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction worksxa0, Energy & Mining, Food & Beverage Shops, Advertising Company, Other
Marketing Type	Ordinary Product
Machinery Test Report	Provided
Body Material:	Aluminum alloy
Video outgoing-inspection	Provided
Action	Double acting type
Fluid	Air
Cushion	Without cushion
Product name:	Standard Cylinder
Type	Source Treatment Unit
Brand	YOLON
Material	carton
Color	Gary
Packaging and delivery
Packaging Details	Standard packing for Hight quality hydraulic power units
Supply Ability
Supply Ability	300 Piece/Pieces per Month

Description

Bore	30-100
way of action	compound action
air medium	Air
Working pressure range	0.1-1.0MPa
Withstand pressure test pressure	1.5MPa
Operating temperature	-20-80℃
Use piston speed	30-800mm/s
buffer form	Adjustable buffer
