Heated Front Window illuminated Automotive Momentary 12mm Push Button Switch SPST IP67

Heated Front Window illuminated Automotive Momentary 12mm Push Button Switch SPST IP67 1

Buy Now

Specifications

Attributes List
Actuation	Momentary
Colour	Black
Contact Configuration	SPST
Contact Material	Gold Plated Silver
Contact Rating	5A 28VDC, 0.2A 48VDC, 0.5A 48VAC
Current Rating	5A @ 28VDC
Illuminated	Yes
Illumination Colour	Yellow
Illumination Voltage	2.1VDC
Material	Zinc Diecast
Mounting Style	Panel
Number of Poles	1
Number of Positions	2
Protection Level	IP67
Operating Temperature	-40°C to +85°C
Panel Cut Out	13.6mm
Panel Thickness	1.5-4mm
Product Series	IP
Switch Operation	Off-(On)
Terminal Type	Flying Leads
Voltage Rating	48VAC/DC

Description

The IPP3FAD2R0Y101X1223-17 is a momentary round push button switch with a 12mm chrome bushing and illuminated with a yellow LED. The switch is prewired with 150mm flying leads and features SPST contacts. Suitable for automotive applications.

Heated rear window illuminated symbol
Momentary NO operation
Yellow LED
LED forward voltage: 2.1V
LED forward current: 20mA
150mm flying leads
SPST contacts
12mm bushing
Sealed to IP67
Panel cut-out: 13.6mm
Solder lug terminals
Rating: 5A 28VDC, 0.2A 48VDC, 0.5A 48VAC
Panel thickness: 1.5-4mm
Dimensions: 29.8 x 17.5mm (height x diameter)
