14mm Lever V3 Microswitch SPDT 16A 250VAC

14mm Lever V3 Microswitch SPDT 16A 250VAC 1

Buy Now

Specifications

Attributes List
Contact Configuration	SPDT
Contact Rating	16A 250VAC
Current Rating	16A
Electrical Life	50,000 Cycles
Number of Positions	2
Operating Force	5N Max
Terminal Type	Quick Connect
Voltage Rating	250VAC

Description

V3 microswitch featuring a 14mm length lever actuator and SPDT contacts. The switch features quick connect terminals and is suitable for domestic and industrial applications.

14mm length lever actuator

Rating: 16A 250VAC

NO / NC contacts

6.3mm quick connect terminals

Operating force: 5N max

Body dimensions: 28 x 10.4 x 15.8mm (Length x Width x Height)
