RGB 16mm Black Momentary Vandal Metal Push Button Switch 12V SPDT

Buy Now

Specifications

Attributes List
Actuation	Momentary
MOQ	1
Colour	RGB
Contact Configuration	NO/NC
Contact Rating	3A 250VAC
Current Rating	3A
Illuminated	Yes
Electrical Life	50,000 Cycles
Illumination Colour	RGB
Material	Zinc Alloy
Mounting Style	Panel
Number of Poles	1
Number of Positions	2
Protection Level	IP65
Operating Temperature	-25°C to +85°C
Panel Cut Out	16mm
Switch Operation	On-(On)
Terminal Type	Quick Connect
Voltage Rating	250VAC

Description

RGB 16mm momentary vandal resistant push button switch featuring a 12V LED and SPDT contacts. The switch is manufactured from zinc and features IP67 protection rating, making it suitable for a wide range of automotive and other 12V applications.

Common anode

1NO 1NC contacts

Momentary switch action

RGB LED

12V LED illumination

2.8x0.5mm terminals

16mm panel cut-out

Rating: 3A 250VAC

Dimensions: 35.2 x 17.8mm (height x diameter)
