Red LED Blue 16mm Round Latching Push Button Switch IP67 IZPR1S412L0S
from
$28.81
Ex Tax: $28.81
10 or more $25.63
25 or more $24.20
50 or more $22.76
100 or more $21.60
- Stock: In Stock
- Model: SCJ014302
- SKU: SCJ014302
Products Sold: 0
Product Views: 423
Ask a Question About This Product
- Description
Red LED Blue 16mm Round Latching Push Button Switch IP67 IZPR1S412L0S
The IZPR1S412L0S is an illuminated rear mounting round sealed latching push button switch with a 16mm bushing and SPST contacts. The switch features IP67 protection rating and solder lug terminals. This makes the switch ideal for applications including automotive and marine.
Button colour: blue LED colour: red LED forward voltage: 1.95V LED forward current: 20mA Panel cut-out: 16.2mm Contacts: momentary SPST Gold plated silver contacts Solder lug terminals Contact rating: 100mA 24VDC Protection rating: IP67 Maximum panel thickness: 3mm Dimensions: 20 x 27.9mm (diameter x height)
